HANGAR 9 Ultra Stick 30cc ARF

HAN2365

Nuovo

Il nuovo Hangar 9® Ultra Stick 30 cc è l’ultimo nato della famiglia Ultra Stick, rinomata e apprezzata per la versatilità e le eccellenti prestazioni di volo. Questo modello dal design sofisticato, con un’incredibile apertura alare di 2 metri, è sotto ogni aspetto un degno rappresentante della serie Ultra Stick. Grazie alla sua personalità sportiva il divertimento è assicurato.

Maggiori dettagli

339,00 €

Dettagli

The first Hangar 9® Ultra Stick™ ARF revolutionised the Stick genre with innovative design twists that really spiced up performance such as a large, double beveled control surface for 3D flight, extra-large control surfaces and optional quad flaps. Building on the legacy of this popular design, the Ultra Stick 30cc ARF provides intermediate to expert pilots a giant-scale sport plane with a wide flight envelope. It features durable construction and an abundance of power options so you can make it as mild or wild as you want. As with its predecessors, the flaps and ailerons are double-beveled so you can take advantage of flaperon and crow mixes. These control surfaces, along with the rudder and elevator, have been oversized for even better 3D capability than before. Hardware and mounting options for Petrol and electric power are included. You can even add floats (sold separately). Enjoy an intoxicating blend of sport-flying fun with this superbly crafted ARF that more than lives up to its name.

Material: Balsa
Wingspan: 206 cm (81.0")
Overall Length: 185 cm (73”)
Wing Area: 87.76 sq dm (1360.3 sq in)
Flying Weight: 5.4 - 6.35kg (12-14 lbs)
Engine Size: 30cc
Motor Size: Power 160
Recommended Motor Battery: 10S 4400-5000mAh
Airfoil Shape: Symmetrical
Minimum Required Radio: 6 channel
Servos: A6180 Digital Aircraft Servo (SPMSA6180)
Recommended Receiver Battery: 6.6V 2200mAh 2S LiFe Receiver Battery (SPMB2200LFRX)
Trim Scheme Colors: White (HANU870), Black (HANU874), Apple Green (HANU903)
Wing Loading: 22 oz./sq. ft.
Prop Size: 17x6 - 18x10
Minimum Speed Control: 80 amp
Control Throw - Low (Ailerons): 3cm up and 2.5cm down
Control Throw - High (Ailerons): 6.8cm up and 5.5cm down
Expo (Ailerons): 25%
Control Throw - Low (Elevator): 2.7cm up and down
Control Throw - High (Elevator): 5.5cm up and down
Expo (Elevator): 20%
Control Throw - Low (Rudder): 3.5cm left and right
Control Throw - High (Rudder): 7 cm left and right
Expo (Rudder): 20%
Control Throw (Flaps): 2.5mm Takeoff and 5.5cm Landing
Wing Tube Length: 65cm
Wing Tube OD: 31cm
Approx Flying Duration: 8 minutes
Experience Level: Intermediate
  • Outstanding flight performance: tried and true Ultra Stick design
  • Flaps for expanded flight envelope
  • Covered in genuine UltraCote™
  • Tail dragger landing gear adds to its sportier looks
  • Large, double beveled control surfaces
  • Two piece plug in wings with aluminium tube provides easy transport and assembly
  • Lightweight balsa/balsa-plywood construction that's strong
  • Float-ready—hard points for mounting the Hangar 9® 1/5-scale Float Set (sold separately) are already built into the fuselage
  • Finished fibreglass wheel pants match UltraCote colors
  • Ready to mount the Evolution® 33GX Petrol Engine
  • Electric motor mount included makes it EP friendly
  • Complete quality hardware included
SPARES
HAN236501 Fuselage
HAN236502 Left Wing with Aileron and Flap
HAN236503 Right Wing w/ith Aileron and Flap
HAN236504 Vertical Stabiliser with Rudder
HAN236505 Horizontal Stab with Elevators
HAN236506 Wing Tube (1.25")
HAN236507 Landing Gear Set
HAN236508 Wheel Pants Set
HAN236509 Aileron and Flap (LH)
HAN236510 Aileron and Flap (RH)
HAN236511 Hardware Set
HAN236512 Decal Set
HAN236513 Fuselage Hatch
HAN236514 Wheel Set
HAN236515 EP Battery Tray
HAN236516 Pushrod Set
HAN236517 Tailwheel Assembly
HAN236518 Fuel Tank 15oz (450cc)
NEEDED TO COMPLETE (RECOMMENDED)
EVOE33GX 33GX 33cc (2.00) Petrol Engine
EVOA112 Evolution 3 Wire Ignition/RX Switch
EVOA100 Optical Ignition Kill Switch
APC17080 Competition Pattern Propeller, 17 x 8
HAN116 Fuel Filler with "T" & Overflow Fitting
HAN502016 3" 2-Blade Aluminium Spinner: Cirrus SR22T 30cc
SPMSA6180 A6180 Digital Aircraft Servo
HAN9154 Aluminium Sx Arm, 1.5" SPM/JR
SPMA3003 Heavy Duty Servo Extension 12"
SPMA3004 Heavy Duty Servo Extension 18"
SPMA3005 Heavy Duty Servo Extension, 24"
SPMAR6600T AR6600T 6-channel Air Integrated Telemetry Receiver
SPMB3000LFRX Spektrum 6.6V 3000mAh 2S LiFe Receiver Battery
EVOM4 Pitts-Style Muffler, Dual Pipe: 33GX
SPMA3058 Standard Y-Harness
OPTIONAL FLOATS
HAN6030 1/5 Scale Float Set
HAN236519 Float Strut Set
OTHER RECEIVER OPTIONS
SPMAR8000 AR8000 8-channel DSMX Receiver
SPMAR7610 AR7610 7-channel DSMX Hi-Speed Receiver
SPMAR7350 AR7350 7-channel AS3X Receiver with integrated telemetry
